13.56MHz MIFARE Classic® EV1 1K RFID Smart Card
MIFARE Classic® EV1 1K, works with durable and high printing quality, is the most widely used contactless smart card.
Electronic Specifications:
1. Chip: MIFARE Classic® EV1 1K
2. Fully ISO/IEC 14443 type A 1-3 compliant
3. Available with ISO/IEC 14443-3 7-byte unique identifier
4. EEPROM size(byte): 1k
5. Write endurance(typical cycles): 200 000 times
6. Organization: 16 sectors with 4 blocks
7. Data Retention: 10 years
8. Bit-rate(Kbit/s): 106
9. Unique serial number(byte): 4 byte NUID or 7 byte UID
10. 4 byte random ID: yes
11. Random number generator: yes
12. Access keys: 2 CRYPTO1 keys per sector
13. Access conditions: Per sector
14. Cryptography: CRYPTO1
15. Frequency: 13.56MHz(HF)
16. Reading distance: 3-10cm
17: NXP originality signature to prove MIFARE Classic® genuineness
Physical Specifications:
1. Material: PVC/ABS/PET/PC/Paper/Wood
2. Diameter: 50mm,
3. Thickness: 1.5mm
4. WaterProof: Yes
5. Laser engraved: Yes
6. Available options: signature panel, hole punching, barcode(QR/39/128/and others), laser engraving, UV printing, scratch off material, LoCo/HiCo magnetic stripe and more
7. Applications: Season passes, Payment, Gym/Club/Spa memberships, loyalty & Promotion, access control and security, employee Identification, Time & attendance, Library card, Parking, Ticketing, hotel room keys, Photo ID, credentials, key cards, mass transit, stored value, dining/vending, hospitality, casino
